Key Features
> 5 inches high resolution colorful LCD display, image can be turned according to position
> Average splice time: 8 seconds
> Average tube-heat time: 20 seconds
> Lithium battery: Rechargable and up to 220 times of continuous splice and heat after fully charged
> X or Y axis Separately views with 520 times magnification, or Simultaneously 230 times
> Cutting-edge technology for image processing
> New developed technology providing strong wind and dust resistance
> Splicing mode: Auto & Manual & Full-Auto
> USB Port
> Storing 10,000 groups of latest splice results
> New technology of fiber core alignment, enhanced accuracy
Specification
|
Applicable Fibers |
Single fiber: SMF (G.652/657), MMF (G.651), DSF (G.653), NZDSF (G.655) |
|
Average Splice Loss |
0.02dB(SM), 0.01dB(MM), 0.04dB(NZDS), 0.04dB(EDF) |
|
Return Loss |
≥60dB |
|
Tension Test |
2.0N(200gf)(Standard) |
|
Typical splicing time |
8 seconds |
|
Typical heating time |
20 seconds |
|
Splicing Program |
50 groups |
|
Protection Sleeve Length |
40mm, 45mm, 60mm |
|
Operating Language |
Chinese, English, French, Portuguese, Spanish |
|
Operating Conditions |
-10~+50°C(operation temperature),0~95% RH(humidity), 0~5000m(altitude) |
|
Power Supply |
AC adaptor: 100~240V input voltage, 50/60Hz; 12V, 5A output voltage(DC) Inner lithium battery: 12V, 6AH |
|
Monitor |
5 inches high resolution colorful LCD display |
|
Fiber Image Magnification |
X or Y axis Separately views 520 times magnification, or Simultaneously 230 times |
|
Storage of Splice Result |
10,000 groups of latest splice results |
|
Splicing Model |
Auto & Manual & Full Auto |
|
Optical Fiber Fixture |
3-in-1 cutting fixture |
|
Dimensions |
130(W)*138.5(D)*135(H)mm; Package size: 52*31*29cm |
|
Weight |
1.69kg+0.38kg (battery weight)=2.06kgs; Package G.W.: 7.6 kgs |
