Specifications
|
Applicable Fibers |
SM, MM, NZ-DS, EDF, Pigtail, Drop Cable (rubber-insulated wire), |
|
|
Average Splice Loss |
0.02dB(SM), 0.01dB(MM), 0.04dB(NZDS), 0.04dB(EDF) |
|
|
Return Loss |
≥60dB |
|
|
Quick splicing time |
8 seconds |
|
|
Quick heating time |
18 seconds |
|
|
Splicing Program |
50 groups |
|
|
Protection Sleeve Length |
20mm, 40mm, 60mm |
|
|
Operating Language |
Chinese, English, French, Portuguese, Spanish,Russia, Thai, Indonesia |
|
|
Operating Conditions |
-10~+50°C(operation temperature),0~95% RH(humidity), 0~5000m(altitude) |
|
|
Power Supply |
AC input |
AC adaptor: 100~240V input voltage, 50/60Hz; |
|
DC input |
15V, 5A output voltage(DC) |
|
|
Battery |
Inner lithium battery: 10.95V, 5.2 AH, Up to 220 times splice and heat |
|
|
Monitor |
Dual cameras, 90︒bi-dirctional view ,4.3 inches high resolution colorful LCD display |
|
|
Fiber Image Magnification |
X or Y Separately 520 times or Simultaneously 270 times |
|
|
Estimated Splice Loss |
Available |
|
|
Cleaving angle detection |
Available |
|
|
Automatic setting |
camera |
Available |
|
Forward motor |
||
|
Tension Test |
1.96~2.25N |
|
|
Storage of Splice Result |
10,000 groups of latest splice results |
|
|
Splicing Model |
Auto & Manual & Full Auto & Stepping |
|
|
Optical Fiber Fixture |
3-in-1 cutting fixture |
|
|
Terminal |
USB for Memorizing and Updating, Mini-USB |
|
|
Dimensions |
124(W)*131(H)*121(D)mm, Package:43*32.5*24.5cm |
|
|
Weight |
1.2kg(without battery pack), Package G.W: 5kgs |
|
Standard Accessories
|
No. |
Item |
Quantity |
|
1 |
Machine |
1 |
|
2 |
Fiber Cleaver |
1 |
|
3 |
Fiber Stripper |
1 |
|
4 |
AC Adaptor (Charger) |
1 |
|
5 |
Battery |
1 |
|
6 |
Spare Electrodes(pair) |
1 |
|
7 |
Cooling Tray |
1 |
|
8 |
Instruction CD & Quick Reference Guide |
1 |
|
9 |
Rubber-insulated wire stripping pliers |
1 |
|
10 |
Carrying Case with Carrying Strap |
1 |
